    1.0mm Electric Resistance Wire Bright Surface 0Cr21Al6 0Cr21Al4 0Cr25Al5

    Ask Lasest Price
    Brand Name : TANKII
    Model Number : 0Cr21Al6 / 0Cr21Al4 / 0Cr25Al5
    Certification : ISO9001
    Price : usd10.1/kg
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 tons/year
    Delivery Time : 5~20 days after getting the payment
    • Product Details
    • Company Profile

    1.0mm Electric Resistance Wire Bright Surface 0Cr21Al6 0Cr21Al4 0Cr25Al5

    FeCrAl Wire 0Cr21Al6 0Cr21Al4 0Cr25Al5 Bare Wire 1.0mm With Bright Surface Used For Heating Furnace



    1. Description
    FECRAL Has been used extensively as heating elements in industrial furnaces and electrical kilns.
    FECRAL Has less hot strength than Tophet alloys but much higher melting point.
    Shanghai TANKII ALLOY MATERIAL Co., Ltd.
    FECRAL AND ALCHROME ALLOY PRODUCER IN China, MOST PROFESSIONAL IN THE WORLD
    We also produce below grades:
    Alkrothal 14, Alloy 750, Alferon 902, Alchrome 750, Resistohm 125, Aluchrom, 750 Alloy, Stablohm 750
    Kanthal A1, Kanthal, Alloy 875, Resistohm 145, Aluchrom 0, Alchrome 875, MWS-875, Stablohm 875, KAF Kanthal AF, Resistohm Y, Aluchrom Y, Alloy 837, AF KAPM KAPM, Alloy 875 PM, Kanthal APM
    Kanthal D, Kanthal, Alloy 815, Alchrome DK, Alferon 901, Resistohm 135, Aluchrom S, Stablohm 812


    2.Specification
    1).Locomotive resistance strip:
    Thickness:0.6mm-1.5mm
    Width:60mm-90mm

    2).Electric ceramic cooktop resistance strip:
    Thickness:0.04mm-1.0mm
    Width:5mm-12mm
    Thickness&Width:(0.04mm-1.0mm)×12mm(above)

    3).Low resistance ribbon:
    Thickness&Width:(0.2mm-1.5mm)*5mm

    4).Industrial furnace ribbon:
    Thickness:1.5mm-3.0mm
    Width:10mm-30mm

    5).Wire: Diameter:0.1mm-8mm



    3. Details of tankii products

    Chemical Composition and Main Property of Fe-Cr-Al Resistance Alloy
    Properties Grade
    1Cr13Al4
    0Cr25Al5
    0Cr21Al6
    0Cr23Al5
    0Cr21Al4
    0Cr21Al6Nb
    0Cr27Al7Mo2
    Main Chemical Composition
    (%)

    Cr
    12.0-15.0
    23.0-26.0
    19.0-22.0
    22.5-24.5
    18.0-21.0
    21.0-23.0
    26.5-27.8
    Al
    4.0-6.0
    4.5-6.5
    5.0-7.0
    4.2-5.0
    3.0-4.2
    5.0-7.0
    6.0-7.0
    Re
    opportune
    opportune
    opportune
    opportune
    opportune
    opportune
    opportune
    Fe
    Bal.
    Bal.
    Bal.
    Bal.
    Bal.
    Bal.
    Bal.






    Nb0.5
    Mo1.8-2.2
    Max Continuous Service Temperature(oC)
    950
    1250
    1250
    1250
    1100
    1350
    1400
    Resisivity 20oC (Ωmm2/m)
    1.25
    ±0.08

    1.42
    ±0.06

    1.42
    ±0.07

    1.35
    ±0.07

    1.23
    ±0.07

    1.45
    ±0.07

    1.53
    ±0.07

    Density(g/cm3)
    7.4
    7.1
    7.16
    7.25
    7.35
    7.1
    7.1
    Thermal Conductivity
    52.7
    46.1
    63.2
    60.2
    46.9
    46.1
    45.2
    (KJ/m@h@oC)
    Coefficient of Thermal Expansion(α×10-6/oC)
    15.4
    16
    14.7
    15
    13.5
    16
    16
    Approximate Melting Point( oC)
    1450
    1500
    1500
    1500
    1500
    1510
    1520
    Tensile Strength(N/mm2)
    580-680
    630-780
    630-780
    630-780
    600-700
    650-800
    680-830
    Elongation(%)
    >16
    >12
    >12
    >12
    >12
    >12
    >10
    Section Variation
    65-75
    60-75
    65-75
    65-75
    65-75
    65-75
    65-75
    Shrink Rate (%)
    Repeatedly Bend Frequency(F/R)
    >5
    >5
    >5
    >5
    >5
    >5
    >5
    Hardness (H.B.)
    200-260
    200-260
    200-260
    200-260
    200-260
    200-260
    200-260
    Continuous Service Time
    no
    ≥80/1300
    ≥80/1300
    ≥80/1300
    ≥80/1250
    ≥50/1350
    ≥50/1350
    Micrographic Structure
    Ferrite
    Ferrite
    Ferrite
    Ferrite
    Ferrite
    Ferrite
    Ferrite
    Magnetic Property
    Magnetic
    Magnetic
    Magnetic
    Magnetic
    Magnetic
    Magnetic
    Magnetic


    Typical application areas of FeCrAl wires

    • Pre-heating of aluminium

    • Homogenising of aluminium

    • Heat treatment in the metallurgical industry

    • Drying of ore concentrates

    • Drying of materials in the wood processing industry

    • Roasting and drying in the food industry

    • Baking in large bakery ovens

    • Drying of chemicals

    • Drying and stoving of paints (stoving furnaces)


    Please call me at +86-18017475212 or email to me for more information on FeCrAl products.
