CuNi6 Resistance Heating Wire For Electrical Heating Mats/Snow Melting Cable

Shanghai Tankii Alloy Material Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap CuNi6 Resistance Heating Wire For Electrical Heating Mats/Snow Melting Cable from wholesalers

    Buy cheap CuNi6 Resistance Heating Wire For Electrical Heating Mats/Snow Melting Cable from wholesalers
    • Buy cheap CuNi6 Resistance Heating Wire For Electrical Heating Mats/Snow Melting Cable from wholesalers
    • Buy cheap CuNi6 Resistance Heating Wire For Electrical Heating Mats/Snow Melting Cable from wholesalers
    • Buy cheap CuNi6 Resistance Heating Wire For Electrical Heating Mats/Snow Melting Cable from wholesalers
    • Buy cheap CuNi6 Resistance Heating Wire For Electrical Heating Mats/Snow Melting Cable from wholesalers

    CuNi6 Resistance Heating Wire For Electrical Heating Mats/Snow Melting Cable

    Ask Lasest Price
    Brand Name : Tankii
    Model Number : 0cr13al4,alloy 750 stablohm 750,0cr23al5,0cr25al5,, 0cr15al5, 0cr20al5,0cr21al6
    Certification : ISO RoHS AISI ASTM GB
    Price : USD 20/Kg
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 200Tons/Month
    Delivery Time : 10-15 woking days
    • Product Details
    • Company Profile

    CuNi6 Resistance Heating Wire For Electrical Heating Mats/Snow Melting Cable

    CuNi6 Resistance Heating Wire for Electrical Heating Mats/Snow Melting Cable


    As a big manufacturer and exporter in China on the line of electric resistance alloy, we can supply all kinds of electric resistance alloy wire and strips (resistance steel wire and strips),
    General Description
    Due to has high tensile strength and increased resistivity values, TANKII copper nickel alloy wires are the first choice for applications as resistance wires. With the different nickel amount in this product range, the characteristics of the wire can be chosen according to your requirements. Copper nickel alloy wires are available as bare wire, or enamelled wire with any insulation and self-bonding enamel. Furthermore, litz wire made of enamelled copper nickel alloy wire are available.
    Features
    1. Higher resistance than copper
    2. High tensile strength
    3. Good bending proof performance
    Application
    1. Heating applications
    2. Resistance wire
    3. Applications with high mechanical requirements
    CharacteristicResistivity ( 200C μΩ.m)Max.working Temperature ( 0C)Tensile Strength (Mpa)Melting point (0C)Density ( g/cm3)TCR x10-6/ 0C (20~600 0C)EMF vs Cu (μV/ 0C) (0~100 0C)
    Alloy Nomenclature
    NC020(CuNi14)0.2300≥31011158.9<30-28

    Copper Nickel Resistance Alloy-CuNi10
    Chemical Content, %
    NiMnFeSiCuOtherROHS Directive
    CdPbHgCr
    100.3--Bal-NDNDNDND

    Mechanical Properties
    Max Continuous Service Temp250ºC
    Resisivity at 20ºC0.15±5%ohm mm2/m
    Density8.9 g/cm3
    Thermal Conductivity50 (Max)
    Melting Point1100ºC
    Tensile Strength,N/mm2 Annealed,Soft210~370 Mpa
    Tensile Strength,N/mm2 Cold Rolled420~740 Mpa
    Elongation(anneal)25%(Min)
    Elongation(cold rolled)2% (Min)
    EMF vs Cu, μV/ºC (0~100ºC)-25
    Micrographic Structureaustenite
    Magnetic PropertyNon

    Application of CuNi10
    CuNi10 low resistance heating alloy is widely used in low-voltage circuit breaker, thermal overload relay, and other low-voltage electrical product. It is one of the key materials of the low-voltage electrical products. The materials produced by our company have the characteristics of good resistance consistency and superior stability. We can supply all kinds of round wire, flat and sheet materials.

    Mechanical Properties

    Type

    Electrical resistivity

    (20degreeΩ

    mm²/m)

    temperature coefficient of resistance

    (10^6/degree)

    Dens

    ity

    g/mm²

    Max. temperature

    (°c)

    Melting point

    (°c)

    CuNi10.03<10008.9/1085
    CuNi20.05<12008.9

    200

    1090
    CuNi60.10<6008.92201095
    CuNi80.12<5708.92501097
    CuNi100.15<5008.92501100
    CuNi140.20<3808.93001115
    CuNi190.25<2508.93001135
    CuNi230.30<1608.93001150
    CuNi300.35<1008.93501170
    CuNi340.40-08.93501180
    CuNi400.48±408.94001280
    CuNi440.49<-68.94001280

    Cu Ni Alloy Wire/strip (CuNi1/CuNi2/CuNi5/CuNi6/CuNi8/CuNi10/CuNi14/CuNi19, CuNi23, CuNi34, CuNi40/CuNi44/CuNi45

    Cu Ni Alloy Wire/strip (CuNi1/CuNi2/CuNi5/CuNi6/CuNi8/CuNi10/CuNi14/CuNi19, CuNi23, CuNi34, CuNi40/CuNi44/CuNi45
    Cu Ni Alloy Wire/strip (CuNi1/CuNi2/CuNi5/CuNi6/CuNi8/CuNi10/CuNi14/CuNi19, CuNi23, CuNi34, CuNi40/CuNi44/CuNi45
    Cu Ni Alloy Wire/strip (CuNi1/CuNi2/CuNi5/CuNi6/CuNi8/CuNi10/CuNi14/CuNi19, CuNi23, CuNi34, CuNi40/CuNi44/CuNi45
