    ASTM / JIS / GB / DIN Nickel Plated Copper Wire 0.02 mm 2.5 mm Round Wire

    Ask Lasest Price
    Brand Name : TANKII
    Model Number : 0.02mm
    Certification : ISO 9001:2008
    Price : USD ( 10 - 60 ) kilogram
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10 tons per month
    Delivery Time : 7 -10 work day
    • Product Details
    • Company Profile

    ASTM / JIS / GB / DIN Nickel Plated Copper Wire 0.02 mm 2.5 mm Round Wire

    Enamelled Mirco Wire Dia 0.02mm Used For Precision Instrument


    Product Description

    These enameled resistance wires have been broadly used for standard resistors, automobile
    parts, winding resistors, etc. using the insulation processing best suited for these applications, taking full advantage of the distinctive features of enamel coating.

    Furthermore, we will carry out enamel coating insulation of precious metal wire such as silver and platinum wire upon order. Please make use of this production-on-order.


    Type Of Bare Alloy Wire

    The alloy we can do enamelled are Copper-nickel alloy wire,Constantan wire,Manganin wire. Kama Wire,NiCr Alloy wire,FeCrAl Alloy wire etc alloy wire

    Size:

    Round wire:0.02mm~2.5mm

    Color of enamel insulation:Red,Green,Yellow,Black,Blue,Nature etc.

    Ribbon Size:0.01mm*0.2mm~1.2mm*5mm

    Moq:5kg each size


    Type of Insulation

    Insulation-enamelled Name

    Thermal Level℃

    (working time 2000h)

    Code NameGB CodeANSI. TYPE
    Polyurethane enamelled wire130UEWQAMW75C
    Polyester enamelled wire155PEWQZMW5C
    Polyester-imide enamelled wire180EIWQZYMW30C
    Polyester-imide and polyamide-imide double coated enameled wire200

    EIWH

    (DFWF)

    QZY/XYMW35C
    Polyamide-imide enamelled wire220AIWQXY

    MW81C



    alloy typechemical composition %

    maximum

    temperature

    resistivity

    Ω·m

    melting

    point℃

    Tensile

    Strength


    magnetism
    CrAlNiFe
    OCr21Al417.0-21.03.0-4.0nonrest11001.23±0.061500750yes
    OCr25Al523.0-26.04.5-6.5nonrest12501.42±0.071500751yes
    OCr21Al6Nb21.0-23.05.0-7.0nonrest13501.43±0.081510752yes
    KSC22.0--24.05.0-7.0nonrest13501.44±0.051510753yes
    OCr27Al7Mo226.8-27.86.0-7.0nonrest14001.53±0.071520754yes
    Cr20Ni8020.0-23.0nonrest≤1.012001.09±0.051400755no
    Cr30Ni7030.0nonrest≤1.012501.18±0.051380756no
    Cr15Ni6015.0-18.0non55rest11501.12±0.051390757no
    Cr20Ni3518.0-21.0non35rest11001.04±0.051390758weak
    Cr20Ni35D19.0-21.0nonrest11001.04±0.051390759weak
    Cr20Ni3O20.0non32rest11001.04±0.051390760

    Type

    Electrical resistivity

    (20degreeΩ

    mm²/m)

    temperature coefficient of resistance

    (10^6/degree)

    Dens

    ity

    g/mm²

    Max. temperature

    (°c)

    Melting point

    (°c)

    CuNi10.03<10008.9/1085
    CuNi20.05<12008.9

    200

    1090
    CuNi60.10<6008.92201095
    CuNi80.12<5708.92501097
    CuNi100.15<5008.92501100
    CuNi140.20<3808.93001115
    CuNi190.25<2508.93001135
    CuNi230.30<1608.93001150
    CuNi300.35<1008.93501170
    CuNi340.40-08.93501180
    CuNi400.48±408.94001280
    CuNi440.49<-68.9400

    1280
