    Corrosion Resistance Copper Nickel Alloy Wire 0.1 - 12.0mm Diameter GB / ASTM

    Ask Lasest Price
    Brand Name : TANKII
    Model Number : C26800
    Certification : ISO SGS
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 200 Tons per month
    Delivery Time : 7-10 work days
    • Product Details
    • Company Profile

    Corrosion Resistance Copper Nickel Alloy Wire 0.1 - 12.0mm Diameter GB / ASTM

    Copper Zinc Alloy CuZn35 CuZn37 CuZn33 0.3mm, 0.4mm, 0.5mm brass wire 5Kg/ spool


    1.Details of EDM wire

    1. Material : CuZn35,CuZn37,CuZn40

    2. Wire diameter: 0.30mm, 0.25mm, 0.20mm,0.15mm,o.10mm

    3. Weight/spool: 3 kg, 5 kg, 7 kg, 15 kg, 20kg

    4. Tensile strength: 1000 N/mm2, 900 N/mm2, 500 N/mm2, 450 N/mm2, N/mm2

    5. Packing: Vacuum packing, sealed with PVC cellephane, moisture proof, quakeproof, and corrosion resistance.

    6. Application: used on low speed wire cutting machines like Agie-charmilles, Sodick, Mitsubishi, Makino


    Zinc Coated EDM Brass Wire Features :

    Wire DiameterToleranceTensile StrengthElongationChemical Composition
    OuterInner
    0.10mm+0/-0.001mm>=900 N/mm2<=3%100% ZnCu 60%,Zn 40%
    0.15mm+0/-0.001mm>=900 N/mm2<=3%100% ZnCu 60%,Zn 40%
    0.20mm+0/-0.002mm>=900 N/mm2<=3%100% ZnCu 60%,Zn 40%
    0.25mm+0/-0.002mm>=900 N/mm2<=3%100% ZnCu 60%,Zn 40%
    0.30mm+0/-0.002mm>=900 N/mm2<=3%100% ZnCu 60%,Zn 40%

    Features of brass wire

    • Abrasion, corrosion, high temperature and spark resistance, non-magnetic.
    • Acid, alkali resistance.
    • Durable, dead soft, good ductility, tensile strength, bright surface.
    • Can be bendable by hand.
    • Convenient to transport and use.
    • Brass wire tarnishes slower than copper wire.

    Application of brass wire

    • Used for ring bands, bracelets and crafts.
    • Used for jewelry components, such as ear wires, chain mail, jump rings, wire wrapped pendants and beaded chain.
    • Widely used in industrial filtration, petroleum, chemical industry, printing, electric cable and other industries.
    • Corrugate brass wire can be used for crimped brushes.

    OTHER BRASS WIRE TECHNICAL PARAMETERS

    Excellent cold processing plasticity, elasticity and high strength.


    ASTM/CDADIN/ENJISGBSPECIFICATIONCHARACTERISTICS AND APPLICATION
    C36000CuZn36Pb3C3602HPb62-3DIA1.0-120.0mm

    Characteristics:Excellent cutting,drilling performance,high strength,good electrical conductivity,strong corrosion resistance.

    Application:Applicable for automatic lathe,CNC lathe processing products,such as the hardware,electrical connectors,connectors.

    --C3601-
    C37700CuZn39Pb2C3771HPb61-1
    C38000CuZn39Pb3C3604HPb60-2
    C35800CuZn40Pb3C3605HPb59-3
    C37000CuZn40Pb2C3710HPb59-1
    ---HPb58-3

    ItemSpecificationCapabilityApplication
    ASTMDINJISGB
    C28000CuZn40C2800H620.3-12.0mmGood cold processing ability with good elastic and tensile strength.Glasses accessory, rivet, battery, fastener, spring and electrode.
    C27400CuZn37C2720H63
    C27000CuZn36C2700H65
    C26000CuZn30C2600H68
    C26000CuZn30C2600H70
    C23000CuZn15C2300H85
    C22000CuZn10C2200H90
    C21000CuZn4C2100H95

    Note: we could provide special size,please contact us.


    chemical composition

    ArticlesChemical composition(wt%)Total Impurity(wt%)
    GB/QBDIN/ASTM/JISCuPbZnFe
    H62JIS C280059.0-63.0≤0.1REM≤0.07-
    H63JIS C272062.0-64.0≤0.07REM≤0.07-
    H65JIS C270063.0-67.0≤0.05REM≤0.05-
    H68C2680064.0-68.5≤0.09REM≤0.05-
    H70JIS C260068.5-71.5≤0.05REM≤0.05-
    H80JIS C240078.5-81.5≤0.05REM≤0.05-
    H85JIS C230084.0-86.0≤0.05REM≤0.05-
    H90JIS C220089.0-91.0≤0.05REM≤0.05
